Ø Maximum Fabric Width |
118” |
|
|
Ø Maximum Table Width |
126” |
|
|
Ø Maximum Roll diameter at Batcher |
20” |
|
|
Ø Maximum Roll Diameter at Output |
20” |
|
|
Ø Forward Speed |
0 – 35 mpm |
|
|
Ø Total power requirement for Roll-Roll |
5 HP / 3 Ph. / 50Hz |
|
|
Ø Paper Tube Outer Diameter |
66 mm |
|
|
Ø Paper Tube Inner Diameter |
50 mm |
|
|
Ø Tube light (under the table) |
6 Nos. |
|
|
Ø Tube light at top |
4 Nos. |
|
|
Ø AC Drive ( 2HP/ 3 PH Inverter) |
2 Nos. |
|
|
Ø Switchgears |
Std. |
|
|
Ø Control gears |
Std. |
|
|
Ø AC Motors (1.5KW/3PH) |
2 Nos. |
|
|
Ø AC Motors (0.75KW/3PH) |
1 Nos |
|
|
Ø Gear Box |
2 Nos. |
|
|
Ø Guide Rollers |
Std. |
|
|
Ø Mechanical Meter |
1 No |
|
|
Ø Laminated plywood sheet |
25 mm Thickness |
|
|
Ø Machine Frame ( MS ) |
3 mm Thickness |
|
|
Ø Inspection Glass |
1 No 5mm Thickness. |
|
